ST-DFLM

TEXTILE FOLDING MACHINE
( DOUBLE FOLDED ON PAPER BOARD )
ST-DFLM Textile Folding Machine is for woven, tulle, jacquard ... fabrics. This machine can be supplied to operate fabrics from plait/loose form to fabrics on slab/card board, or with various other fabric inlet options.

ST-DFLM Textile Folding Machine is for woven, tulle, jacquard ... fabrics. This machine can be supplied to operate fabrics from plait/loose form to fabrics on slab/card board, or with various other fabric inlet options.



● Ergonomically designed
● Fast and easily handled, requiring for one operator only
● Improve fabric quality
● Synchronize production process
● Reduce administration



WARRANTY EXTENSION IS AVAILABLE AT SUNTECH THAN OTHER SUPPLIERS.

ST-DFLM Textile Folding Machine:



Speed: 0 - 70m/min
Fabric Width: 1.8 - 4.0 meters
Major Axis Max.: 700mm
Dimensions(LXWXH): 2660X2120X2300mm (for model ST-DFLM-180 only)
Weight: 1000kgs (for model ST-DFLM-180 only)
Electric Specs: 3Phase - 380V; 50HZ (can be adjusted to suit for different countries)
Remark: Variable working width is possible and can be tailor-made to your requirements of processing needs.



ST-DFLM Textile Folding Machine:



1). Doubling, lapping, measuring any type of fabrics with inlet from plait/loose fabrics, rolls or batchers and with outlet on slabs/card board.



2). For proper folding, special systems for thin and sensitive fabrics.



3). Automatic alignment of selvedge on the doubling triangle with very sensitive and precise photo-electric guide.



4). Reliable measuring with electronic calibrated counter meter system.



5). Hard or loose folding feature, due to torque controlled, from inlet of fabric to end of fabrics on slab/card board.



6). Foot switch is used to withdraw the finished fabrics and send the empty sword plate.



7). Automatic printing on selvedge, checking table, printing of measuring - Optional
