Non woven fabric slitting machine is one of the mechanical equipment for slitting wide-width non-woven fabric, paper, mica tape or film into multiple narrow-width materials. It commonly be used in paper making machinery, wire and cable mica tape and printing or packaging machinery. It is especially suitable for slitting of narrow tapes (non-woven fabrics, insulating materials, mica tapes, films, etc.). Non woven slitting machine can be mainly used for slitting of non-woven fabrics, mica tapes, paper, insulating materials and films. It is Tidland who created the first non woven slitting machine in the world. According to different needs in the production process, the non woven slitting machine can slit wide-width materials into different narrow slide materials. This machine is based on the original electronic control system with the addition of automatic edge-aligner control which improves the stability of the machine during high-speed operating process. It achieves the function of flat winding, simple and convenient operation, safe and reliability, and strong durability of the machine.
Machine Features
1. Using ultrasonic welding
It saves the trouble of frequently changing needles and threads and provides no broken thread joints like traditional thread stitching, which achieves the neat partial cutting and sealing of textiles production. It guaranteed the high quality of products because of its strong adhesion, waterproof effect achievement, and clear embossing with three-dimensional relief effect on product surface.
2. The ultrasonic and special steel wheel processing
The sealed edge will not crack because of it, also it will not damage the edge of the cloth, and there is no burr or curling phenomenon.
No preheating required during manufacture. And can be operated continuously.
3. Easy Operation
It is not much different from the traditional sewing machine operation method, which can be operated by ordinary sewing workers.
4. Low cost
Five or six times faster than traditional machines, and high efficiency.
Non Woven Fabric Slitting Machine
The main Purpose
This machine is mainly used for edge trimming or slitting of wide-width rolls such as non-woven fabrics. Cut into several rolls of actual required size, and the narrowest can be cut to 18mm edging strips. Whether it is one-time slitting or two- or three-time slitting, domestic slitting machine manufacturers should devote energy to research on the frame structure, and design a more reasonable slitting machine from the perspective of slitting machine manufacturers. The advanced slitting machine makes the structure of slitting different materials more detailed. In the next round of competition in the international market, it will provide favorable weapons for film-making enterprises, and at the same time, find a blue ocean for their own industry.
Main Structure
1. Rack part, it is welded by thick steel plate, it is stable and firm, and the angle is balanced,
2. Rewinding part, the rewinding part is easy for manually operation,
3. Unwinding part, the maximum unwinding diameter can reach 600~700mm,
4. Cutter part, the knife distance can be adjusted between 18mm-1600mm.
5. Host part, it mainly adopts 5 KW motor and is equipped electronic speed control system.
6. Guide roller part, the whole machine is made of chrome-plated steel pipes, each of which has been dynamically balanced.
Note
1. Before starting the machine, the speed of the host should be adjusted to the lowest speed,
2. Pay attention to safety when installing the blade, protect yourself from scratching the blade,
3. The place where the machine needs to be refueled should be regularly maintained,
4. It can work in high and low speed and forward and reverse switching control,
5. This machine is equipped with double-sided sharpening system, using diamond grinding, the blade does not need to be disassembled. The knife can be sharpened, and the blade remains sharp for a long time to achieve the best cutting quality. It also comes with a vacuuming capacity to keep the fabric and track clean,
6. One-step material setting, fast and efficient.
7. It should be installed in a dry, ventilated, well-lit environment so that can be easy to operate.
