AGV (Automatic Guided Vehicle) is an automatic guided vehicle, which is an unmanned automatic handling vehicle powered by a battery, equipped with a non-contact guiding device and an independent addressing system. Its system technology and products have become important equipment and technologies for flexible production lines, flexible assembly lines, and warehousing and logistics automation systems. SUNTECH is a manufacturer with over 50 years of experience in textile machinery manufacturing. We combine AGV technology with storage and handling equipment, hoping to contribute to the automation upgrade of the textile industry. I will briefly introduce SUNTECH's motorized beam trolley with AGV technology.
I. The basic structure of AGV beam transport trolley
.png)
1) Body: It is composed of the frame and the corresponding mechanical devices. It is the basic part of the AGV and the installation basis of other assembly components.
2) Power storage and charging device: AGVs often use 24V and 48V DC or AC batteries as power. The battery power supply should generally be maintained for more than 8 hours of continuous work.
3) Driving device: It is composed of wheels, reducers, brakes, driving motors and speed controllers. It is a device that controls the normal operation of the AGV. The operating instructions are issued by computer or manual control. The adjustment is controlled by the computer respectively. For safety, the braking device can be mechanically braked when the power is cut off.
4) Guiding device: It accepts the direction information of the guiding system and realizes the steering action through the steering device.
5) On-board controller: accepts the instructions of the control center and executes the corresponding instructions, and at the same time feeds back its own state (such as position, speed, etc.) to the control center in time.
6) Communication device: realize information exchange between AGV and ground control station and ground monitoring equipment.
7) Safety protection devices: including the protection of the AGV itself, the protection of people or other equipment, etc.
8) Transfer device: a device that is in direct contact with the goods being transported to realize the transfer of the goods.
9) Information transmission and processing device: monitor the AGV, monitor the ground state of the AGV, and transmit information in real time with the ground control station.
II. Features of AGV
High degree of automation, charging automation, beauty, safety, cost control,
Ease of maintenance, predictability, reduced product damage, improved logistics management, smaller site requirements, flexibility, long distance transportation.
III.Types of AGV
1) According to the navigation method: direct coordinate navigation method, electromagnetic navigation method, magnetic navigation method, laser navigation method, optical navigation method, inertial navigation method, image recognition navigation method, GPS (Global Positioning System) navigation method.
2) According to the drive mode: single drive, differential drive, dual drive, multi-wheel drive.
3) According to the transfer method: push-pull type, roller type, chain type, belt type, traction type, piggyback type, fork type, picking type, gantry type, robot type.
4) According to the communication method: wired communication, infrared light communication, radio communication, wireless local area network.
SUNTECH's motorized beam trolley with AGV technology can intelligently help customers to transport and lift the beam and achieve unmanned operation, which can greatly improve work efficiency. And SUNTECH is a professional worldwide enterprise with decades of experience and research. We are committed to providing customers with excellent products and customized service. Our experienced experts will offer customers timely and effective integrated services in pre-sales consultation, sales, maintenance, and comprehensive after-sales support, giving customers the ultimate and comprehensive service experience.If you are interested in the beam transport trolley with AGV technology , please contact us freely.
