Beam Stacker is used for the purpose of storing warp beam, weaving beams, fabric rolls, and control panel in order to facilitate straightforward operation. This beam stacker serves as a smart storage system since it has the ability to identify the beam location, choose the shortest route to doffing beam automatically, and link to an ERP system to make data exchange possible. Beam Stackers may be designed by SUNTECH to fit the available space of the client, the number and kind of beams to be stored, and the optimal amount of beams to store.
The computerized warp beam storage system, also known as a beam stacker, is the best solution for the storage of warp beam, size beam, weaving beam, and cloth beam. These systems are widely applicable in the weaving preparation workshop, weaving unit, and finishing unit for the purposes of maximizing space utilization and preventing damage to ready warp and cloth beam. They are offered in a variety of models to accommodate the management of each specific circumstance. For instance, loading and unloading may be accomplished from a single point to several spots on the same level or on a higher or lower level.
The model ST-BS could employ a microprocessor-controlled information system for storage and retrieval of particular beams.
1) Enclosed Control Panel with PLC for sequential control of machine.
2) HMI (Touch Panel) for easy and quick access of data and machine operation.
3) Automatic Beam Selection based on entered data like beam No./beam code/mill code/etc. Machine will select shortest path and bring the selected beam at doffing position.
4) Safety controls are interlocked with machine operation.
.jpg)
SUNTECH beam stacker is global sales no.1. However, before you start to purchase this beam stacker at SUNTECH, you may have some questions. To help you solve the questions, we’ve collected some questions frequently asked and you can read the following FAQ. We hope these questions can help you a lot.
Q1: What information we need to collect from the customer to get the beam stacker drawing?
SUNTECH: We need below information to prepare the beam stacker drawing.
1)Space Available(Length x Width x Clear Height)
2)Their expected storage quantity
3)The beam brand/working width/flange diameter/tube length/weight
Q2: What’s the storage quantity of your beam stacker?
SUNTECH: The storage quantity is related to how much space the customer can provide.
We provide customized solution for each customer, the more bigger space they can provide, then the bigger storage quantity.
Q3: Will SUNTECH send engineers to install the beam stacker?
SUNTECH: Becasue of covid-19, we can not send our Chinese engineers to install the beam stacker, but our Bangladesh and Pakistan technical team could help the customer install the beam stacker, the customer need pay for additional installation cost, airfare, accommodation, meals, covid test cost.
Q4: 1.Does one Beam Stacker can store different beams with different specs but from one brand?
SUNTECH: As long as the beam Flange Diameter, Beam Tube Length, Beam Weight etc. is within the application of beam stacker, we could make design to storage these different beams.
Q5: Does one Beam Stacker can store different beam with different specs but and from different brand?
SYes, it could. But customer shall inform Brand, storage quantity for different brand and beam specs for different brand. Because different brand, the beam head and central height is different, the running chain that we will make will be different accordingly.
E.G.:
For Example, if ST-BS-120 Which is suitable for 80 Picanol Beams and 40 Toyota Beams, then there are two choices for customer:
Plan A) Only one pair of loading chains on one shaft, 80 pcs loading chain suitable for Picanol Beams only, 40 pcs for Toyota Beams only.
For example No.1-80 is suitable for Picanol, No. 80-120 is suitable for Toyota Beams.
Then when loading Picanol Beams, operator needs to choose No. from 1-80; when loading Toyota Beams, operator needs to choose No. from 80-120.
Plan B) Adding 80 pcs extra chains on No.80-120(two pairs of loading chain for each shaft), one pair of loading chain for Picanol beams, and another one pair of loading chain for Toyota beams. Then all the shafts are suitable for Picanol Beams. When loading Toyota Beams, they just need choose No. between 80-120 is OK. It will be much easier for using.
That’s all. Our professional team can provide you free customized solution to save your time and space to the greatest extent. Don’t hesitate to get in touch with us!
