The fabric measure and cutting machine is used to measure and cut fabric to the required size and shape, after evolving over the years, becoming more efficient, automated, and accurate. This blog will mainly discuss the structure of the fabric measure and cutting machine in detail, letting others have a more specific concept about the fabric measure and cutting machine.
The Main Structure of the Fabric Measure and Cutting Machine
The fabric measure and cutting machine is composed of several critical components that work together to achieve accurate results, and the most important of them is as follows.
1. Measuring system
The measuring system is one of the essential components, ensuring that the fabric is cut to the required size and shape. It consists of a ruler or tape measure attached to the cutting table, which is calibrated in centimeters or inches to ensure accuracy. The measuring system is adjustable and can be set to different measurements, allowing for flexibility in the production process.
2. Cutting system
The cutting system is another vital component of the fabric measure and cutting machine. It is responsible for cutting the fabric to the required size and shape. There are two types of cutting systems used in fabric measure and cutting machines - manual and automatic. Manual cutting systems require the operator to use handheld cutting tools such as scissors or rotary cutters to cut the fabric. Automatic cutting systems, on the other hand, use computer-controlled cutting tools like lasers or water jets to cut the fabric. Automatic systems are faster, more precise, and reduce waste, making them the preferred choice for many manufacturers.
Structure of the Fabric Measure and Cutting Machine
The fabric measure and cutting machine's structure consists of various components that work together to ensure precise and accurate cutting of fabric, there are other structures of it.
1. Frame and base
The frame and base, which are usually made of steel or cast iron, strong and durable materials, are the foundation of the fabric measure and cutting machine and provide the necessary support and stability required for the machine to operate effectively.
2. Cutting table
The cutting table is designed to ensure that the fabric remains flat and taut during the cutting process. It is usually made of a smooth and durable material such as stainless steel or tempered glass, which helps to prevent the fabric from slipping or shifting during cutting, which can result in inaccuracies.
3. Clamping system
The clamping system holds the fabric in place during cutting, ensuring that it remains flat and taut. This system usually consists of clamps or vacuum suction cups.
4. Software and control system
The software and control system controls the cutting process. Software is installed on a computer that is connected to the cutting machine, allowing for precise control of the cutting tool. The control system uses sensors and switches to monitor the process and ensure accuracy and safety.
5. Safety features
Fabric measure and cutting machines are designed with safety features to protect the operator and the machine. Emergency stop buttons, safety guards, and sensors that detect abnormalities in the cutting process are examples of safety features.
6. Maintenance
Regular maintenance is necessary to ensure the machine operates effectively and efficiently. Cleaning the machine, lubricating moving parts, and replacing worn-out components are some of the maintenance tasks that should be performed.
SUNTECH ST-HRM Cloth Rolling Machine ( Fabric Rolling Machine )
SUNTECH ST-HRM cloth rolling machine ( fabric rolling machine ) is the newest product of SUNTECH, which use high quality steel, which greatly improves the efficiency and service life of our products. SUNTECH ST-HRM cloth rolling machine ( fabric rolling machine ) can adapt to various working environments because the steel we use is resistant to corrosion, acid, alkali, salt, and atmospheric environment, high temperature, good impact resistance, and fatigue resistance. The tensile strength of our steel d is more than 8-10 times that of ordinary steel. Our raw materials come from large steel mills of international standards and are processed and selected through layers.
The SUNTECH ST-HRM cloth rolling machine is specially designed for fabric distributors or retailers with length counting, rewinding, weighing and cross-cutting functions. It provides convenient and accurate length counting for all kinds of fabric rolls.
There are the main functions of ST-HRM
1. Precise length counting
Selectable meters and yards for readout, length presetting, counting error <0.1m/km;
2. Full-width fabric detection
Fixed flat inspection screen ensuring full-width fabric detection;
3. Sturdy reel seat
It is for the upcoming fabric roll unrolling;
4. Stable roll output
With adjustable roll stiffness and movable wheels
5. foot switch and optional linear cloth end cutter
A foot switch for easy stop/start control
Conclusion
In conclusion, fabric measure and cutting machine are essential equipment in the textile industry. The machine's structure consists of lots of components, which work together to ensure precise and accurate cutting of fabric. SUNTECH ST-HRM cloth rolling machine is the most outstanding product in the world and is praised by customers.
SUNTECH provides the textile industry machines to the whole world, helps them to improve the efficient, decrease the labor costs. SUNTECH offers numerous types of textile machinery: visual inspection defects, fabric measure and cutting machine, fabric swatch cutter, beam truck, trolley lift system, fabric roll cutting machine etc. If you are interested in us, please contact us now!
